Stock # D24

Joskin Modulo2

Call for Price
“Infinitely” modular manure tanker at an attractive price!
Capacities (l)
 2500 → 18000
Single axle/Double axle
General Points

The Modulo2 manure tanker has a self-supporting structure. Available in single-axle version from 2,500 to 11,000 l and double-axle version from 8,400 to 20,000 l, it is the bestseller in the range of JOSKIN manure tankers. Several thousand Modulo2s are in use throughout the world and have been providing a quality service for decades. The secret of its success undoubtedly lies in adaptability: the buyer can indeed design the tanker according to his/her wishes using industrialised modules (pump system, filling arm, etc.). The tanker will consist of these modules and will therefore meet the buyer’s precise requirements. The industrial manufacturing process guarantees the compatibility of the modules and a flawless efficiency of the machine.


Sale Type
4000ME 5000ME 6000ME
Manure tanker reference
0208V-20 0214V-20 0215V-20
(1)(3) / /
Model of the tanker
2500ME 3200ME 4000ME 5000ME 6000ME
Theoretical capacity of the tank without recessing
Theoretical capacity (l)
2.529 3.278 4.262 5.101 6.031
Theoretical capacity of the tank with recessing
Theoretical capacity (l)
/ / / / 5.823(2)
Standard pump
MEC4000/M MEC4000/M MEC4000/M MEC5000/M MEC5000/M
Standard axle
ADR60X1500-6G ADR60X1500-6G ADR60X1500-6G ADR90X1900-8G ADR90X1900-8G
Brake drum
250X60 250X60 300X60 350X90 350X90
Type of standard parking stand
Manual Manual Manual Manual Manual
Tank diameter
1135 1135 1300 1300 1400


7000ME 8400ME 9000ME 10000ME 11000ME
Manure tanker reference
0216V-20 0217V-20 0061V-20 0218V-20 0250V-20
Legend / / / / /
Model of the tanker
7000ME 8400ME 9000ME 10000ME 11000ME
Theoretical capacity of the tank without recessing
Theoretical capacity (l)
7.096 8.507 / 10.054 11.290
Theoretical capacity of the tank with recessing
Theoretical capacity (l)
6.854(2) 8.103(2) 8.952 9.554(2) 10.738(2)
Standard pump
MEC5000/M MEC6500/M MEC8000/M MEC8000/M MEC8000/M
Standard axle
ADR90X1900-8G ADR100X2000-8G ADR100X2000-10G ADR100X2000-10G ADR100X2000-10G
Brake drum
350X90 350X90 406X120 406X120 420X180
Type of standard parking stand
Manual Manual Manual Manual Manual
Tank diameter
1500 1600 1800 1700 1800








ALPINA2 Narrow Machine
Self-Supporting Monocoque Tank

The Modulo2 has a sturdy and light design with a low centre of gravity for an outstanding weight/maneuverability ratio. The tanks, which are made of hot-dip galvanised high tensile steel (4 mm thick from 2,500 to 5,000 l, 5 mm from 6,000 to 8,400 l and 6 mm from 9,000 to 20,000 l), are in compliance with the EN707 (pitching) security standard. An integral cradle is welded by a robot underneath the tank, on its entire length, creating a monocoque, self-supporting structure. The drawbar, running gear and potential pre-equipment for spreading implement (option) are fastened to this cradle, which concentrates all traction strains and protects in this way the tank from any unnecessary stress.

ALPINA2 Narrow Machine Running Gear

All Modulo2 are fitted with a bolted running gear. This concept is particularly useful because a slurry tanker is usually an investment for several years (or even generations) and requirements can vary over time. The running gear can be moved forwards or backwards to adapt the load distribution, e.g. when adding a spreading implement at the back of the machine. On a single-axle Modulo2, the axle is bolted on the tank brackets. On the double-axle version, the tanker is fitted with a Joskin Roll-Over bogie that is characterised by its upward pull line, an off-centre pivot axis and ergonomic parabolic leaves for an outstanding maneuverability and comfort (clearance up to 24 cm!).

ALPINA2 Narrow Machine Drawbar and Drawbar Suspension

The Modulo2 manure tankers are standard fitted with a “V-shaped” open drawbar housing the pump system to protect it from any accidental contact with the tractor wheels. The drawbar of the Modulo2 with vacuum pump is reversible: at any time, you can switch your tanker from the "high hitch” configuration (+/- 1 m from the ground) to the "low hitch” configuration (+/- 50 cm from the ground) without having to change the drawbar (180° rotation on the horizontal axis), and vice versa. Depending on the model, the Modulo2 is standard fitted with a bolted fixed drawbar with cross-suspension or silent-blocks. Comfort is therefore on the program!

ALPINA2 Narrow Machine Adaptability and Pump System

The Modulo2 can be fitted with various pumps: vacuum, GARDA system (combination of vacuum pump + emptying centrifugal pump and spreading gun) or spiral pump. It therefore offers effective solutions to all users. Next to an efficient pump system, the comfort of use and the machine specifications can further be improved thanks to specific modules for filling or unloading arm (“JUMBO” front arm on the left/right, self-supporting double arm, dorsal boom or unloading arm), mixing systems into the tank (hydraulic or air mixer), etc. In short: a tanker 100% adaptable to your needs!

ALPINA2 Narrow Machine Spreading Implements

Moving the running gear to the back is often essential for good load distribution when adding an injection implement on the Modulo2. However, with a Penditwist or Pendislide BASIC spreading boom (6 - 7.5 m), this shift is very limited.


special features

Standard equipment

  • Manufactured in special steel (HLE)
  • Tank galvanized inside and outside
  • Manufactured according to EN707 and CE/97/23 standards
  • 6-spline Walterscheid P.T.O.-shaft
  • 4 m PVC pipe (Ø 6")
  • Hose-carrying hooks on both sides (single-axle model) or hose-carrying mudguards (double-axle model)
  • Exact scatterer
  • Perrot couplings
  • Single bulb road lights
  • Wheels 11.5x15 10 PR for models from 2500 to 4000 ME
  • Wheels 400R22.5 cover for models from 5000 ME to 18000 MEB

Specific equipment

  • Monocoque structure (galvanized brackets of 1.000 mm welded on the whole tank length)
  • Adjustable bolted running gear (adjustable position)
  • Air braking system
  • Drawbar with cross-springs or rigid drawbar
  • Low hitching
  • Ø 50 mm bolted flat eyelet (small plate) (-> 16000)
  • JOSKIN Ø 80 mm 3T bolted knee-joint eyelet (large plate) (18000)

Specific equipment model 9000 ME

  • Wheel cases with mudguards

Specific equipment model MEB (double axle)

  • JOSKIN Roll-Over bogie with parabolic leaves (1.350 mm to 14000 MEB and 1.600 mm from 16000 MEB)

Specific equipment VACUUM

  • Vacuum pump with forced greasing
  • Pressure relief valve (Ø 6")
  • Anti-spill valve (pump security)
  • Self-cleaning syphon (30 l)
  • Ø 100 mm pressure gauge
  • 2 half-circular indicators (Ø 2")
  • 3 flanged outlets (Ø 6"): left and right, and left on the rear wall
  • Manhole (Ø 600 mm) at the back of the tank
  • Rear hydraulic valve (Ø 6")
